The quick exhaust valves are able to quickly discharge the air contained in a circuit; if applied on a cylinder they allow to increase the return speed of the stem.
| CODE | 3D FILE | A | B | F | GR |  |
|---|---|---|---|---|---|---|
| VGL005 | 13,5 | 4,5 | M5 | 0,4 | 10 | |
| VGL008 | 20,5 | 5 | G1/8 | 1 | 10 | |
| VGL004 | 25,5 | 5,8 | G1/4 – G3/8 | 3 | 10 | |
| VGL002 | 35,5 | 8,2 | G1/2 | 5 | 10 | |
| VGL001 | 40,5 | 9 | G3/4 – G1 | 34 | 10 |
The quick exhaust valves are able to quickly discharge the air contained in a circuit; if applied on a cylinder they allow to increase the return speed of the stem.
| CODE | 3D FILE | A | B | F | GR | |
|---|---|---|---|---|---|---|
| VGL005 | 13,5 | 4,5 | M5 | 0,4 | 10 | |
| VGL008 | 20,5 | 5 | G1/8 | 1 | 10 | |
| VGL004 | 25,5 | 5,8 | G1/4 – G3/8 | 3 | 10 | |
| VGL002 | 35,5 | 8,2 | G1/2 | 5 | 10 | |
| VGL001 | 40,5 | 9 | G3/4 – G1 | 34 | 10 |
